Duplex / Jacketed Metallic Hose

Overview

A Flexmetallic jacketed hose is a type of flexible hose assembly that consists of an inner hose or core, made of convoluted stainless steel, surrounded by another hose referred to as the outer jacket or casing. The space between the inner hose and the outer hose jacket is often filled with a heat transfer medium, such as steam or hot oil, which circulates around the inner hose to provide heating or cooling as needed.

Applications

Jacketed hoses are commonly used in industrial applications where temperature control is critical, such as in chemical processing, food and beverage production, pharmaceutical manufacturing, and more. They are designed to withstand high temperatures and pressures, making them suitable for conveying a wide range of fluids, including hot or cold liquids, gases, and steam.

The inner hose of a jacketed hose assembly is typically chosen based on the specific requirements of the application, taking into account factors such as chemical compatibility, temperature resistance, and pressure rating. Common materials for the inner hose is stainless steel, but PTFE (polytetrafluoroethylene), and other metals or polymers are sometimes supplied depending on the application.

Purposes

Insulation
The outer jacket provides insulation to the inner hose, helping to maintain the desired temperature of the fluid being conveyed
Protection
It protects the inner hose from external damage, abrasion, and environmental factors, extending the lifespan of the hose assembly.
Containment
In applications where the conveyed fluid is hazardous or needs to be contained, the outer jacket helps to prevent leaks and spills, enhancing safety and regulatory compliance.

Configurations and Designs

Jacketed hoses are available in various configurations and jacketed designs, with options for different materials, sizes, and end fittings to suit specific application requirements. They offer a versatile and reliable solution for industries that require precise temperature control and fluid handling capabilities.

Custom Solutions

Custom Solutions
Flexmetallic offers custom solutions in order to meet specific customer requirements.
Consultation and Design
Flexmetallic engineering team works closely with our customers to understand their needs and requirements for jacketed hoses. We can offer consultation services to assess the application and recommend suitable solutions.
Material Selection
Based on the application requirements, Flexmetallic assists our customers to select the appropriate materials for the inner hose, outer jacket, and any other components of the hose assembly. This may involve considering factors such as temperature, pressure, chemical compatibility, and environmental conditions.
Testing and Quality Assurance
Before delivery, Flexmetallic hoses undergo thorough testing and quality assurance checks on the hose assemblies to ensure they meet the required performance standards and specifications. This includes pressure testing, leak testing, dimensional checks, and material analysis.

Industries

Industries
Engineering / Building Industry / HVAC
Metallic hose assemblies provide durability and flexibility, enhancing HVAC systems' efficiency and longevity
Industries
Petrochemical
Resilient metallic hose assemblies ensure safe fluid transfer in demanding petrochemical environments.
Industries
Cryogenics
Metallic hose assemblies withstand extreme cold, crucial for transferring cryogenic fluids efficiently and reliably.
Industries
Data Centres
Flexible metallic hose assemblies facilitate cooling fluid circulation, maintaining optimal temperatures.
Industries
High Pressure
Robust metallic hose assemblies enable secure fluid transport in high-pressure ensuring safety and efficiency.
Industries
Fire suppression
Durable metallic hose assemblies are integral to fire suppression systems, delivering reliable fluid distribution.
